HT Series - High temperature NTC Thermistor

FEATURES

The working temperature range of HT Series - High temperature NTC Thermistor is -50~180℃ (can work at 200℃ in short time), which is suitable for motorcycle water temperature sensor.

1. High-temperature resistance, high precision

2. Fast response

3. High reliability, high stability

4. Working temperature: -50~180℃ (can work at 200℃ in short time)

5. Meet the requirement of RoHS

APPLICATION

1. Automobile

2. Motorcycle water temperature sensor

3. Products which need to be measured in high temperature environment

Part Number Identification

Electronic Parameter Specification

Part No.	Resistance Value R_25℃(KΩ)	B Value (25/50℃)B(K)	Rated Power @25℃（mW）	Dissipation Factor(mW/℃)		Thermal Time Constant (S)
HT215R6£3438F	0.2156(@100℃)	3438(25/100℃)	≈200		≈2	≤10
HT202£3470A	2	3470
HT103£3425B	10	3435(25/85℃)
HT103£3950A	10	3950
HT203£3950A	20	3950
HT104£4100A	100	4100

◆ Special specifications can be customized according to customer requirements

Package
